Sale!

7Inch Video Door Security Intercom System

Original price was: $289.00.Current price is: $229.00.

Have the option to talk with and view your guests on arrival!

Description

Features

– With micro-processing technology, auto-remote control, excellent performance and high reliability  T

– The TFT 7 inch digital colour LCD for monitor

– Clear night-viewing, 24 hour monitoring, calling, talking and unlocking remote & ID & Password controlling

– Additional monitor available up to 6(optional) and 3 outdoor cameras at most

– TFT colour screen with low power consumption, no radiation and high definition

– Hands-free intercommunication

– Brightness, picture and volume adjustable

– 25-chord melody rings for option

– Cabling: 4-core connection cable



Specifications

  1. Type: Wired Video Door phone & LCD Wired Indoor Monitor
  2. Wiring requirements: 30 meters: RVV4 x 0.5mm;50 meters: RVV4 x 0.75mm;100 meters: RVV4 x 1.0mm
  3. Monitor: 7-inch TFT-LCD 800 x480
  4. Imaging Sensor: 1/3 CMOS
  5. Illumination: 0 Lux
  6. Working temperature: -15-55 degrees
  7. Relative humidity: 10 % ~ 90%(RH)
  8. Dissipation: stand-by <0.5W working <10W
  9. Talk time delay: 60 seconds
  10. Monitor time delay: 60 second
  11. Power Source : Adapter input voltage: AC100-240V 50Hz-60Hz
  12. Adapter output voltage current: DC15V 1500mA

– With 4 wires system connection. Using 4-core cables to connect the camera and monitor.

The max distance is up to 100 meters. Different distance, use different diameter cable, please check the following from to choose corresponding cable. ( We will send 5 meters cable , for the longer cable, need to buy by yourself when installing)

Door Phone
  • Dimensions: 93 x 130 x 30mm (W x H x T )
  • Installation: Surface mounting
  • Case: ABS Engineering Plastics
  • Viewing angle: 92 degrees
  • Power Adapter: Shared indoor unit
  • Night vision illumination distance; 1 meter
  • Illumination: 0 Lux
  • Camera: 1/3 CMOS

Packing includes

  • 1 x Outdoor Camera
  • 1 x Indoor Monitor
  • 1 x Hanging plate
  • 1 x Power Adapters
  • 1 x 4-core connection cable
  • 1 x 2-core connection cable
  • 1 x Screws
  • 1 x Manual
